IPIP隧道创建实例
本实例中通过在两台VMWare虚拟机之间创建ipip6隧道，实现IPv4 over IPv6通信。
两台VMWare虚拟机通过NAT DHCP服务器连通，并手动配置静态IPv6地址。
网络环境
在VMWare中安装了两台虚拟机Ubuntu18.04和Ubuntu24.04，其中Ubuntu18.04的internet口和Ubuntu24.04的ens33口连接VMWare的NAT DHCP服务器。
下面是Ubuntu24.04的ens33口的配置信息：
$ sudo cat /etc/netplan/50-cloud-init.yaml
# This file is generated from information provided by the datasource. Changes
# to it will not persist across an instance reboot. To disable cloud-init's
# network configuration capabilities, write a file
# /etc/cloud/cloud.cfg.d/99-disable-network-config.cfg with the following:
# network: {config: disabled}
network:
ethernets:
ens33:
addresses:
- 192.168.100.128/24
- 2001:db8::1/64
dhcp4: true
optional: true
version: 2
$ ifconfig ens33
ens33: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500
inet 192.168.100.128 netmask 255.255.255.0 broadcast 192.168.100.255
inet6 fe80::20c:29ff:fe54:b940 prefixlen 64 scopeid 0x20<link>
inet6 2001:db8::1 prefixlen 64 scopeid 0x0<global>
ether 00:0c:29:54:b9:40 txqueuelen 1000 (Ethernet)
RX packets 13290201 bytes 14862347751 (14.8 GB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 6009878 bytes 2955096378 (2.9 GB)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
可以看到ens33口配置了静态IPv4地址192.168.100.128和IPv6地址2001:db8::1。
接下来是Ubuntu18.04的internet口的配置信息：
root@ubuntu:~# cat /etc/netplan/01-network-manager-all.yaml
# Let NetworkManager manage all devices on this system
network:
version: 2
renderer: NetworkManager
ethernets:
internet:
dhcp4: yes
dhcp6: yes
addresses: ["2001:db8::2/64"]
#addresses: [8.8.8.8/32, 8.8.4.4/32]
wan:
dhcp4: no
dhcp6: no
addresses: [192.168.202.254/24,8.8.8.8/32,8.8.4.4/32,"2020::ff/64","2020::fe/64"]
root@ubuntu:~# ifconfig internet
internet: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500
inet 192.168.100.134 netmask 255.255.255.0 broadcast 192.168.100.255
inet6 2001:db8::2 prefixlen 64 scopeid 0x0<global>
inet6 fe80::250:56ff:fe2c:f5ed prefixlen 64 scopeid 0x20<link>
ether 00:50:56:2c:f5:ed txqueuelen 1000 (Ethernet)
RX packets 280234 bytes 320719568 (320.7 MB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 125452 bytes 18174330 (18.1 MB)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
可以看到Ubuntu18.04的internet口的IPv4地址是由NAT DHCP服务器动态分配的，为192.168.100.134，和Ubuntu24.04的IPv4地址在同一网段。其IPv6地址为手动指定的，值为2001:db8::2/64。
拓扑介绍完毕，接下来创建IPv4 Over IPv6隧道。
隧道创建
首先在Ubuntu24.04上创建隧道，创建脚本create_tunnel.sh内容如下：
#!/bin/bash
# 判断隧道是否存在，如果存在则删除
if ifconfig | grep tun0 >/dev/null ;then
ip -6 tunnel del tun0
fi
# 创建隧道，指定隧道接口名称tun0 隧道模式ipip6 远端IPv6地址和本地IPv6地址
ip -6 tunnel add tun0 mode ipip6 remote 2001:db8::2 local 2001:db8::1
# 给隧道添加IPv4地址
ip addr add 10.0.0.1/24 dev tun0
# 启用隧道接口
ip link set tun0 up
# 添加IPv4路由
route add -net 10.0.0.0/24 dev tun0
# 显示隧道
ip -6 tunnel show
执行结果如下:
$ sudo ./create_tunnel.sh
ip6tnl0: ipv6/ipv6 remote :: local :: encaplimit 0 hoplimit inherit tclass 0x00 flowlabel 0x00000 (flowinfo 0x00000000)
tun0: ip/ipv6 remote 2001:db8::2 local 2001:db8::1 encaplimit 4 hoplimit 64 tclass 0x00 flowlabel 0x00000 (flowinfo 0x00000000)
$ ifconfig tun0
tun0: flags=209<UP,POINTOPOINT,RUNNING,NOARP> mtu 1452
inet 10.0.0.1 netmask 255.255.255.0 destination 10.0.0.1
inet6 fe80::4427:f1ff:fe8e:d94a prefixlen 64 scopeid 0x20<link>
unspec 20-01-0D-B8-00-00-00-00-00-00-00-00-00-00-00-00 txqueuelen 1000 (UNSPEC)
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 8 bytes 2157 (2.1 KB)
TX errors 2 dropped 2 overruns 0 carrier 0 collisions 0
route -n
Kernel IP routing table
Destination Gateway Genmask Flags Metric Ref Use Iface
0.0.0.0 192.168.100.2 0.0.0.0 UG 100 0 0 ens33
10.0.0.0 0.0.0.0 255.255.255.0 U 0 0 0 tun0
接下来在Ubuntu18.04上创建脚本create_tunnel_peer.sh内容如下：
#!/bin/bash
# 判断隧道是否存在，如果存在则删除
if ifconfig | grep tun0 >/dev/null ;then
ip -6 tunnel del tun0
fi
# 创建隧道，指定隧道接口名称tun0 隧道模式ipip6 远端IPv6地址和本地IPv6地址
ip -6 tunnel add tun0 mode ipip6 remote 2001:db8::1 local 2001:db8::2
# 给隧道添加IPv4地址
ip addr add 10.0.0.2/24 dev tun0
# 启用隧道接口
ip link set tun0 up
# 添加IPv4路由
route add -net 10.0.0.0/24 dev tun0
# 显示隧道
ip -6 tunnel show
注意IPv6地址需要互换，同时IPv4地址需要保证在同网段。
执行结果如下：
root@ubuntu:~# ./create_tunnel.sh
ip6tnl0: ipv6/ipv6 remote :: local :: encaplimit 0 hoplimit inherit tclass 0x00 flowlabel 0x00000 (flowinfo 0x00000000)
tun0: ip/ipv6 remote 2001:db8::1 local 2001:db8::2 encaplimit 4 hoplimit 64 tclass 0x00 flowlabel 0x00000 (flowinfo 0x00000000)
root@ubuntu:~# ifconfig tun0
tun0: flags=209<UP,POINTOPOINT,RUNNING,NOARP> mtu 1452
inet 10.0.0.2 netmask 255.255.255.0 destination 10.0.0.2
inet6 fe80::3caf:fff:fe95:67a2 prefixlen 64 scopeid 0x20<link>
unspec 20-01-0D-B8-00-00-00-00-00-00-00-00-00-00-00-00 txqueuelen 1000 (UNSPEC)
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
root@ubuntu:~# route -n
Kernel IP routing table
Destination Gateway Genmask Flags Metric Ref Use Iface
0.0.0.0 192.168.100.2 0.0.0.0 UG 101 0 0 internet
10.0.0.0 0.0.0.0 255.255.255.0 U 0 0 0 tun0
到此处为止，隧道已经创建完成。
验证
由于是IPv4 over IPv6隧道，因此首先需要验证IPv6地址是否通畅。
# 在Ubuntu24.04上ping Ubuntu18.04的IPv6地址
$ ping 2001:db8::2
PING 2001:db8::2 (2001:db8::2) 56 data bytes
64 bytes from 2001:db8::2: icmp_seq=1 ttl=64 time=0.247 ms
64 bytes from 2001:db8::2: icmp_seq=2 ttl=64 time=0.215 ms
64 bytes from 2001:db8::2: icmp_seq=3 ttl=64 time=0.533 ms
64 bytes from 2001:db8::2: icmp_seq=4 ttl=64 time=0.237 ms
64 bytes from 2001:db8::2: icmp_seq=5 ttl=64 time=0.358 ms
^C
--- 2001:db8::2 ping statistics ---
5 packets transmitted, 5 received, 0% packet loss, time 4056ms
rtt min/avg/max/mdev = 0.215/0.318/0.533/0.118 ms
# 反之亦然
root@ubuntu:~# ping 2001:db8::1
PING 2001:db8::1(2001:db8::1) 56 data bytes
64 bytes from 2001:db8::1: icmp_seq=1 ttl=64 time=0.268 ms
64 bytes from 2001:db8::1: icmp_seq=2 ttl=64 time=0.299 ms
64 bytes from 2001:db8::1: icmp_seq=3 ttl=64 time=0.722 ms
64 bytes from 2001:db8::1: icmp_seq=4 ttl=64 time=0.359 ms
^C
--- 2001:db8::1 ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3080ms
rtt min/avg/max/mdev = 0.268/0.412/0.722/0.181 ms
接下来验证IPv4地址是否通畅，这里通畅会存在问题，即未设置IPv4地址路由，导致IPv4 ping不通。
$ ping 10.0.0.2
PING 10.0.0.2 (10.0.0.2) 56(84) bytes of data.
64 bytes from 10.0.0.2: icmp_seq=1 ttl=64 time=0.290 ms
64 bytes from 10.0.0.2: icmp_seq=2 ttl=64 time=0.263 ms
64 bytes from 10.0.0.2: icmp_seq=3 ttl=64 time=0.223 ms
64 bytes from 10.0.0.2: icmp_seq=4 ttl=64 time=0.259 ms
^C --- 10.0.0.2 ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3101ms
rtt min/avg/max/mdev = 0.223/0.258/0.290/0.023 ms
root@ubuntu:~# ping 10.0.0.1
PING 10.0.0.1 (10.0.0.1) 56(84) bytes of data.
64 bytes from 10.0.0.1: icmp_seq=1 ttl=64 time=0.270 ms
64 bytes from 10.0.0.1: icmp_seq=2 ttl=64 time=0.273 ms
64 bytes from 10.0.0.1: icmp_seq=3 ttl=64 time=0.287 ms
64 bytes from 10.0.0.1: icmp_seq=4 ttl=64 time=0.544 ms
^C
--- 10.0.0.1 ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 3070ms
rtt min/avg/max/mdev = 0.270/0.343/0.544/0.117 ms
下面是在Ubuntu24.04上的tun0口的抓包结果：
tun0口的抓包结果显示只是普通的ICMP交互报文，这是以为IPv6报文被转发到该接口之前已经被解封装了。
下面是在ens33口的抓包结果，ens33口是和Ubuntu18.04连通的接口。
通过ens33接口抓包数据可以看到，IPv6报文的目的地选项中的下一个头部类型被设置为IPIP，因此可以确定ICMP报文是通过IPv4 over IPv6隧道传输的。
Ubuntu18.04的internet口的抓包结果和ens33口相同。
